Pramac GDW370I/FS2 | 296kW Diesel Generator | Three-Phase | FPT Engine

Powered by the FPT C13TE2A 12.9-litre six-cylinder turbocharged and aftercooled diesel engine and paired with a Mecc Alte ECO38 2L4 C alternator, it delivers 370kVA / 296kW Emergency Standby Power and 350kVA / 280kW Prime Power.



Pramac GDW370I/FS2 | 296kW Diesel Generator | Three-Phase | FPT Engine

The Pramac GDW370I/FS2 is a heavy-duty industrial diesel generating set engineered for applications requiring reliable high-capacity three-phase power.

At its heart is the FPT C13TE2A, a 12.9-litre six-cylinder turbocharged and aftercooled diesel engine operating at 1500rpm. The engine features electronic speed governing, water cooling and a 24V electric starting system.

The generator delivers 370kVA / 296kW Emergency Standby Power and 350kVA / 280kW Prime Power, making it suitable for both emergency backup applications and extended operation under variable electrical loads.

FPT Industrial Diesel Engine

The FPT C13TE2A combines strong power output with robust industrial construction.

Key engine characteristics include:

• 12,880cm³ / 12.9-litre displacement
• Six cylinders in-line
• Turbocharged and aftercooled aspiration
• Electronic speed governor
• Water-cooled design
• Stage II emissions level
• 24V electric starting system
• 35-litre oil capacity
• 48-litre coolant capacity
• Maximum PRP lube oil consumption of approximately 0.2% of fuel consumption

The engine develops up to 345kWm gross mechanical power in ESP operation and 314.9kWm in PRP operation.

Mecc Alte Alternator

Electrical generation is handled by the Mecc Alte ECO38 2L4 C brushless alternator.

The alternator provides a 370kVA standby rating at 27°C and a 350kVA continuous nominal rating at 40°C.

It delivers approximately 93.5% efficiency at full load, together with Class H insulation, IP23 protection and approximately ±1% voltage tolerance.

Fuel Consumption & Runtime

Fuel consumption is approximately:

54.60 litres per hour at 75% Prime Power

70.19 litres per hour at 100% Prime Power

A wide range of optional fuel tank capacities is available from 500 litres up to 4,000 litres.

Depending on the selected configuration, approximate runtime at 75% PRP ranges from 9.16 hours to 73.26 hours.

Automatic Mains Failure Control

The optional ACP Automatic Control Panel provides Auto Mains Failure functionality for standby applications.

The system offers full generator monitoring and protection, detailed event and performance logging, remote control compatibility and optional I/O expansion.

Parallel Generator Operation

The optional MPP Modular Parallel Panel enables the GDW370I/FS2 to operate in parallel with other generating sets.

Up to 32 generator sets can be configured for parallel operation, making this model suitable for large industrial installations, load sharing and redundancy applications.

Open & Canopy Versions

The GDW370I/FS2 is available in both open-frame and weatherproof canopy configurations.

The canopy version uses galvanized sheet-steel construction and quality soundproofing materials to protect the generator while reducing operating noise.

The standard canopy provides approximately:

• 97 dB(A) guaranteed sound power
• 78 dB(A) sound pressure at 1 metre
• 68 dB(A) sound pressure at 7 metres

An Extra Silent canopy is also available with a guaranteed sound power level of approximately 94 dB(A).

Typical Applications

The Pramac GDW370I/FS2 is suitable for industrial facilities, manufacturing plants, warehouses, commercial buildings, construction projects, infrastructure, utilities, agriculture, emergency standby systems and prime power installations.

With its combination of FPT engine technology, Mecc Alte alternator performance and 296kW standby output, the GDW370I/FS2 provides a dependable power solution for demanding three-phase applications.
