Pramac GDW265B/FNE | 210kW Diesel Generator | Three-Phase | Baudouin Engine

The Pramac GDW265B/FNE is a powerful three-phase diesel generator delivering up to 262.7kVA emergency standby power and 237kVA prime power. Powered by a Baudouin six-cylinder turbocharged engine and fitted with a Mecc Alte brushless alternator, it provides dependable power for industrial, commercial and standby applications. Its weatherproof, soundproofed canopy offers excellent protection, straightforward servicing and reduced noise levels.



Pramac GDW265B/FNE 210.2kW Diesel Generator

The Pramac GDW265B/FNE is a powerful three-phase diesel generator developed for demanding commercial, industrial and emergency backup applications. Delivering 210.2kW (262.7kVA) emergency standby power and 189.6kW (237kVA) prime power, it provides a reliable electricity supply for factories, warehouses, construction projects, agricultural facilities, commercial premises and critical infrastructure.

Powered by a robust Baudouin 6M16G4D0/S diesel engine, the generator combines strong performance with dependable operation. The 9.73-litre, six-cylinder in-line engine features turbocharged and aftercooled aspiration, electronic speed governing and an efficient water-cooling system. It operates at 1,500rpm and is supplied as a non-emissions-certified engine.

The Baudouin engine is paired with a premium Mecc Alte ECO38 2M4 C alternator. Its brushless, four-pole design incorporates Class H insulation, IP23 protection and a voltage tolerance of ±1%, helping it deliver consistent and stable electrical output under changing load conditions.

The generator produces 400/230V three-phase electricity at 50Hz, with a power factor of 0.8. Its electrical system provides a nominal current of 342A, a maximum current of 379A and protection through a 400A circuit breaker.

Fuel consumption is approximately 38.66 litres per hour at 75% prime load and 50.89 litres per hour at 100% prime load. Optional fuel tanks ranging from 650 to 4,000 litres allow operating autonomy to be matched to the requirements of the installation, with calculated running times of up to 103.47 hours at 75% prime load.

The GDW265B/FNE is available in open, soundproof canopy and extra-silent canopy configurations. The standard canopy version produces a noise pressure level of 68dB(A) at seven metres, while the extra-silent enclosure reduces the guaranteed sound power level from 97dB(A) to 94dB(A) LWA.

Available control solutions include an Automatic Control Panel (ACP) with Automatic Mains Failure functionality and a Modular Parallel Panel (MPP). These control options provide comprehensive generator monitoring, protection, event logging, remote connectivity and support for parallel installations containing up to 32 generating sets.

Manufactured in accordance with applicable ISO 8528 requirements, the Pramac GDW265B/FNE is an excellent choice for organisations requiring powerful, dependable and professionally engineered prime or emergency standby power.

Features & Benefits

• 210.2kW / 262.7kVA emergency standby power

• 189.6kW / 237kVA prime power

• Baudouin 6M16G4D0/S diesel engine

• Six-cylinder, 9.73-litre engine

• Turbocharged and aftercooled aspiration

• Electronic speed governor

• Water-cooled engine system

• Mecc Alte ECO38 2M4 C alternator

• Brushless, four-pole alternator

• Class H alternator insulation

• IP23 alternator protection

• Stable three-phase electrical output

• 400/230V output at 50Hz

• 400A circuit breaker

• 24V electric starting system

• Automatic Mains Failure control available

• Parallel operation with up to 32 generators available

• Open, soundproof and extra-silent versions

• Standard canopy noise level of 68dB(A) at seven metres

• Fuel-tank capacities from 650 to 4,000 litres

• Up to 103.47 hours of calculated runtime

• Suitable for industrial, commercial and backup power

Technical Specifications

• Emergency Standby Power: 262.7kVA / 210.2kW

• Prime Power: 237kVA / 189.6kW

• Voltage: 400/230V

• Frequency: 50Hz

• Phases: Three-phase

• Power Factor: 0.8

• Fuel: Diesel

• Engine: Baudouin 6M16G4D0/S

• Emission Level: Non-emissions certified

• Alternator: Mecc Alte ECO38 2M4 C

• Starting System: 24V electric

• Nominal Current: 342A

• Maximum Current: 379A

• Circuit Breaker: 400A
