Pramac GDW145B/FNE | 118kW Diesel Generator | Three-Phase | Baudouin Engine

The Pramac GDW145B/FNE is a powerful three-phase diesel generator delivering 148kVA / 118.4kW standby power and 134.8kVA / 107.8kW prime power. It combines a turbocharged Baudouin engine with a brushless Mecc Alte alternator for dependable industrial, commercial and emergency backup power.



Pramac GDW145B/FNE 148kVA / 118.4kW Three-Phase Diesel Generator

The Pramac GDW145B/FNE Three-Phase Diesel Generator is engineered to provide dependable power for demanding commercial, industrial and standby applications. It is suitable for factories, warehouses, construction projects, agricultural operations, commercial premises and emergency backup installations.

The GDW145B/FNE delivers 148kVA / 118.4kW of Emergency Standby Power (ESP) and 134.8kVA / 107.8kW of Prime Power (PRP). Its 400/230V three-phase output provides the capacity required to operate industrial machinery, electrical equipment and commercial power systems.

At the heart of the generator is a Baudouin 6M11G2D0/S six-cylinder diesel engine with a 6,750cc displacement. The engine is turbocharged and aftercooled, with a water-cooled system that helps maintain a controlled operating temperature during extended use.

An electronic speed governor provides precise control over the engine’s nominal operating speed of 1,500rpm. The electric starting system and 12V electrical circuit support reliable and straightforward operation.

The Baudouin engine is paired with a Mecc Alte ECP34 2M 4C brushless alternator. This four-pole alternator features Class H insulation, IP23 protection and an efficiency rating of 92.9% at full load. It delivers stable three-phase power at 50Hz with a 0.8 power factor.

Fuel consumption is approximately 21.67 litres per hour at 75% prime power and 28.34 litres per hour at 100% prime power. Fuel tank options range from 350 to 2,200 litres, allowing the generator’s operating time to be configured around the needs of the installation.

The standard canopy version features a weather-resistant galvanised sheet-metal enclosure. High-quality soundproofing and a residential silencer help reduce noise emissions, while large lateral doors with key-lockable handles provide convenient access for servicing and maintenance.

The canopy version has a stated sound pressure level of approximately 68dB(A) at seven metres. An Extra Silent enclosure is also available for installations where stricter noise controls apply.

Manual Remote Start, Automatic Control and Modular Parallel control panels are available. These options allow the generator to be configured for manual operation, automatic mains-failure backup or parallel operation involving multiple generating sets.

Features & Benefits

• 148kVA / 118.4kW emergency standby power
• 134.8kVA / 107.8kW prime power
• Stable 400/230V three-phase output
• Baudouin 6M11G2D0/S diesel engine
• Six-cylinder in-line configuration
• 6,750cc engine displacement
• Turbocharged and aftercooled aspiration
• Water-cooled engine system
• Electronic speed governor
• Electric starting system
• Mecc Alte ECP34 2M 4C brushless alternator
• Class H alternator insulation
• IP23 alternator protection
• 92.9% alternator efficiency at full load
• Fuel tank options from 350 to 2,200 litres
• Weather-resistant galvanised steel canopy
• Extra Silent enclosure available
• Large, lockable service-access doors
• Manual, automatic and parallel control options
• G2 load-acceptance classification under ISO 8528-5
• Suitable for standby and prime-power applications

Technical Specifications

• Emergency Standby Power (ESP): 148kVA / 118.4kW
• Prime Power (PRP): 134.8kVA / 107.8kW
• Voltage: 400/230V
• Frequency: 50Hz
• Power Factor: 0.8
• Phases: Three-phase
• Maximum Current: 214A
• Nominal Current: 195A
• Circuit Breaker: 250A
• Fuel Type: Diesel
• Engine Manufacturer: Baudouin
• Engine Model: 6M11G2D0/S
• Engine Displacement: 6,750cc
• Cylinders: Six in-line
• Aspiration: Turbocharged and aftercooled
• Cooling System: Water-cooled
• Nominal Engine Speed: 1,500rpm
• Speed Governor: Electronic
• Starting System: Electric
• Electrical System: 12V
• Alternator Manufacturer: Mecc Alte
• Alternator Model: ECP34 2M 4C
• Alternator Type: Brushless
• Alternator Poles: Four
• Alternator Protection: IP23
• Insulation Class: Class H
• Fuel Consumption at 75% PRP: 21.67L/h
• Fuel Consumption at 100% PRP: 28.34L/h
• Open Version Dimensions: 3,055 × 1,200 × 1,643mm
• Open Version Weight: 1,574kg
• Canopy Version Dimensions: 3,702 × 1,200 × 2,050mm
• Canopy Version Weight: 2,111kg
• Canopy Noise at 7m: 68dB(A)
